Ancient technology

HDD

• a spinning thingy
• sequential IO >>> random IO
• FlushFileBuffers/fsync is heavy

How to build a fast appender

• append only file (sequential IO)
• flush every n writes
• reuse a file when data not needed
• WAIT! It's a database log file!

SQL Server

• Microsoft database system
• *.mdf = data
• *.ldf = log
• not documented fn_dblog

SQL Server db log

SQL Server LSN

• example LSN "00000014:00000153:021f"
• 00000014 - VLF sequence number
• 00000153 - offset to the log block
• 021f - offset inside the log block

SQL Server Operations

• LOP_INSERT_ROWS
• LOP_MODIFY_ROW
• LOP_MODIFY_COLUMNS
• LOP_BEGIN_XACT
• LOP_COMMIT_XACT
• ...

SQL Server

• operation appended to the log
• log is flushed to disk
• tables not neccessarily (held in memory)
• queries are not logged

SQL Server Summary

• every operation has LSN
• log contains all operations
• tables are "just" snapshots
• you could "easily" read log file
• Change Data Capture works in this way

Event Store

• functional, event oriented, by Greg Young(TM)
• OSS
• based on streams/aggregates
• hosts projections (async js handlers)

Event Store API

• Append Events ("my-stream", events, expectedVersion: 5)
• Read Stream ("my-stream", from: 10)
• From All (eventTypes: ["cardIssued", "cardBlocked"])

Event Store architecture

• one logical append-only log file
• an event position = file position
• all writes are linearlized

Event Store log

Event Store indexing

Event Store indexing

• level 0: log of the database
• level 1: index
• level 2: system projections: ByEventType, ByStreamPath, IndexStreams
• level 3: your js projections
• level 4: your js projections based on lvl 3

Event Store projections

• handlers of selected events
• can be partitioned (by user name, by date)
• can store state per partition

Event Store projections

Counting all the active cards

fromAll().
  when({
    $init: function() { return {counter: 0}; },
    CardIssued: function(s,e) { s.counter += 1; },
    CardBlocked: function(s,e) { s.counter -= 1; },
    });

Event Store projections

• to read all events: Log
• to read events from a stream: Index -> Log
• to read all event of type x: ByEventType -> Log
• to mark what was processed just store the position (8 bytes)

Event Store summary

• every event has a physical position
• there's one index (stream, version, position)
• other indexes are just streams
• only increasing position - universal marker

Kafka

• a distributed streaming platform
• cluster -> topics -> partitions
• Producer/Consumer

Kafka architecture

• don't fear the filesystem (TM)
• writes: append + fsync
• reads: SendFile/TransmitFile

Kafka consumers

• Consumer Position is just an integer for a partition
• Consumer Position can be client side or server side
• Consumer Position is stored in __consumer_offsets after OffsetCommitRequest

Kafka summary

• an append only log
• cluster -> topic -> partition
• only increasing position per partition

Service Fabric

• universal service orchestrator
• abstraction over hosting, balancing, HA
• can host: guest services (Node, PHP), stateful, stateless, actors

Stateful services

• stateful services & actors - same base
• reliable collections & actor state
• service > partitions > replicas

Replicas

• replica = persistent log + snapshoting
• replica: primary, active secondary, secondary
• replication factor (min, expected) defined by you

Service Fabric summary

• .NET stateful services use log
• log is replicated via replicator
• snapshoting, storing data is done for you by SF

Distributed consensus

• systems: Cassandra (transactions), CockroachDB, Zookeeper, EventStore
• cluster for replicating data
• algorithms: Paxos, Raft, Zab
• available when (n/2 + 1) nodes active

Distributed consensus - how to

If we had a list of commands: c1, c2, c3, c4

• and replicated them in the same order
• and applied them in the same order
• then the result would be the same on every machine

Distributed consensus summary

• even distributed consensus = logs
